Phaser 6125/6130 Color Laser Printer Service Manual 3-37
Error Messages and Codes
Jam at Manual Feed Slot
Paper fed from the Manual Feed Slot did not reach the Registration Sensor on
time.
Initial Actions
■ Try picking paper from the tray.
■ Check the paper path for obstructions or debris.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map Reference
■ Drive Clutch Assy Kit, PL3.1.99
■ Left Side Harness Assy, PL3.1.18
■ Photo Sensor, PL3.2.13
■ Actuator SSI, PL3.2.14
■ Main Drive Assy, PL7.1.2
■ MCU Board, PL8.2.13
■ “Map 2 - Laser Unit, Feeder Assembly”
on page 10-9
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “Feeder, Manual Feed, & Registration” on
page 10-19
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the paper size
Does the paper size meet the
specification?
Go to step 3. Use the paper
that meets the
specifications,
then go to step
2.
2 Does the error still occur when
printing?
Go to step 3. Complete
3 Check the paper condition
Is the paper in the Manual Feed Slot
wrinkled or damaged?
Replace with a
new and dry
sheet, then go to
step 4.
Go to step 5.
4 Does the error still occur when
printing?
Go to step 6. Complete
5 Insert a fresh sheet of paper in the
Manual Feed Slot.
Does the error still occur when
printing?
Go to step 6. Complete

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
