Phaser 6125/6130 Color Laser Printer Service Manual 3-75
Error Messages and Codes
MCU NVRAM Error
Engine NVRAM is corrupted.
Applicable Chain Link
■ 041-340: MCU NVRAM Error
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Note
Press the Down Arrow, Up Arrow, and OK buttons simultaneously to
display error code detail called for in this procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Toner Cartridge, PL5.1.21/5.1.22/
5.1.23/5.1.24
■ Transfer Unit, PL6.1.7
■ MCU Board, PL8.2.13
■ “Map 1 - Transfer Unit, Control Panel,
Imaging Unit, Dispenser, Fuser” on
page 10-8
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “Xerographic” on page 10-24
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the error
Does the error still occur when turning
off and on the power?
Go to step 2. Complete
2 Check the failure parts
Is the “ADDR: 1***” displayed?
Replace the
MCU Board
(page 8-59).
Go to step 3.
3 Check the failure parts
Is the “ADDR: 30**” displayed?
Replace the
Transfer Unit
(page 8-41).
Go to step 4.
4 Check the failure parts
Is the “ADDR: 31**” displayed?
Replace the
Yellow Toner
Cartridge.
Go to step 5.
5 Check the failure parts
Is the “ADDR: 32**” displayed?
Replace the
Magenta Toner
Cartridge.
Go to step 6.
6 Check the failure parts
Is the “ADDR: 33**” displayed?
Replace the
Cyan Toner
Cartridge.
Replace the
Black Toner
Cartridge.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
