5-8 Phaser 6125/6130 Color Laser Printer Service Manual
Print-Quality Troubleshooting
Test Prints
This section provides information for how to analyze test prints. A variety of
test prints are available for determining the quality of output from the printer
and to assist in troubleshooting the problems.
■ No Image IOT
■ Pattern IOT
■ Grid 2 ESS
■ Cyan 20% ESS
■ Magenta 20% ESS
■ Yel l ow 2 0% E S S
■ Black 20% ESS
■ CMY 20% ESS
■ Gradation ESS
No Image IOT
This test print provides a sample of blank
page. This test is used to identify
problems with the printer function.
■ Fail: Check the printer function.
■ Pass: Check the network
connection, cable, PC...etc.
s6180-318

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
