Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 3-63
Error Messages and Codes
Replace Fuser / Fuser Life
The Fuser has reached end of life.
Applicable Chain Link
■ 010-351: The Fuser is at end of life.
5 Check the resistances of Temp. Sensor
in the Fuser
Remove the Fuser.
Warning: Start the operation after the
Fuser has cooled down.
Check the resistances across the
following pins of the removed Fuser.
J171-5 <=> J171-4
J171-6 <=> J171-8
J171-6 <=> J171-7
Can the resistances be measured?
(The resistances are 7 k-ohm at 180
degrees C).
Replace the
MCU Board
(page 8-59)
Replace the
Fuser
(page 8-9).
After replacing
the Fuser, be
sure to reset the
life counter
value.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
Fuser (PL6.1.1)
MCU Board (PL8.2.13)
■ “Map 2 - Laser Unit, Feeder Assembly”
on page 10-9
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “Feeder, Manual Feed, & Registration” on
page 10-19
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the life counter value of the
Fuser
Does the life counter value show the
near of the end?
Replace the
Fuser
(page 8-9).
After replacing
the Fuser, be
sure to reset the
life counter
value.
Go to step 2.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
