Xerox Phaser 6125 Service Manual

10-24 Phaser 6125/6130 Color Laser Printer Service Manual
Plug/Jack and Wiring Diagrams
Xerographic
MCU
PL8.2.13
P/J42
5
6
7
8
9
10
Imaging Unit X Pro Harness
PL9.1.11
Humidity Harness
PL9.1.6
Imaging Unit
PL4.1.21
P/J422
6
5
4
3
2
1
+3.3VLD
DATA
CLOCK
+3.3VDC
SG
+3.3VDC
CLOCK
DATA
SG
+3.3VLD
1
2
3
4
Imaging
Unit
EEPROM
P/J144
4
3
2
1
SG
+5VDC
HUMI.
TEMP.
P/J20
1
2
3
4
P/J201
4
3
2
1
PWBA EEPROM
PL8.2.16
Humidity Sensor
PL8.2.7
LVPS Harness
PL9.1.3
ERASE Y/M/C ON (L) +3.3VDC
ERASE K ON (L) +3.3VDC
+3.3VDC
P/J14
15
16
17
P/J141
3
2
1
Erase LED
PL4.1.8
1
2
3
4
Left Side Harness
PL3.1.18
Transfer Assembly
PL6.1.7
5
4
3
2
1
+5VDC
ADC SENSOR
LED REM
ADC V MONI
5
1
2
3
4
5
SG
P/J2811P/J281P/J28
5
4
3
2
1
ADC
Sensor
s6130-063
+3.3VDC
+3.3VDC
+3.3VDC
+5VDC
To Laser Unit

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
