Xerox Phaser 6125 Service Manual

4-6 Phaser 6125/6130 Color Laser Printer Service Manual
General Troubleshooting
Service Mode Menu Map
6130 Menu Map - Page 1
Engine Diag
Print Info
ESS Diag
Power Saver
On/Off
OK
Exit
Service Mode
All Test
CodeROM Test
FontROM Test
EEPROM Test
DRAM Test
MAC+PHY Test
ASIC Test
PANEL Test
Engine Test
Info Page
Print Settings
Installation
SerialNo.
Tone Correction
Display Counter*
HexDump
Pixel Counter
Configuration*
Counter Type*
Print Counter
CopyCounter MtoB
CopyCounter BtoM
Clear All NVM
Clear JobHistory
Clear AuditronPV*
Sensor Test
Motor Test
NVM Settings
Color Print
B/W Print
Total Print
Color Backup
B/W Backup
Total Backup
Color Error
B/W Error
Edit NVM
Save NVM to ESS
Load NVM from ESS
Initialize Slave
Print NVM Info
Main Motor FULL2
Main Motor FULL1
Main Motor HALF
Sub Motor FULL2
Sub Motor FULL1
Sub Motor HALF
K Mode Solenoid
Tray Feed Solenoid (Half)
Tray Feed Solenoid (Init)
Fan HIGH
Fan LOW
Yellow Toner Motor
Magenta Toner Motor
Cyan Toner Motor
Black Toner Motor
Regi Clutch
Tray Feed Solenoid
(Auto)
Drum Erase Lamp K
Drum Erase Lamp YMC
s6130-201
To access Service Mode, press Up and Down Arrows at power ON.
Manual Feed Sensor
Tray No Paper
Regi Sensor
Exit Sensor
K Mode Sensor
Side Switch
Cover Open Sensor
*Not used in this printer

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
