Phaser 6125/6130 Color Laser Printer Service Manual 3-69
Error Messages and Codes
Sub Motor Error
The Sub Motor has failed.
Applicable Chain Link
■ Chain Link 042-326: Sub Motor Error
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MCU Board, PL8.2.13
■ Sub Drive Assembly, PL7.1.1
■ “Map 1 - Transfer Unit, Control Panel,
Imaging Unit, Dispenser, Fuser” on
page 10-8
■ “Map 3 - LVPS, Drive Motors, I/P Board,
AC Power” on page 10-10
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Imaging Unit and Fuser for
correct installation. Are the Imaging
Unit and Fuser correctly installed?
Go to step 3. Reseat the
Imaging Unit
and Fuser.
Go to step 2.
2 Does the error still occur? Go to step 3. Complete.
3 1.Close the Front Cover.
2.Perform the Sub Motor test
(page 4-28): Service Mode >
Engine Diag > Motor Test > Sub
Motor FULL2.
Does the Sub Motor operate properly?
Replace the
MCU Board
(page 8-59).
Go to step 4.
4 Check the wiring harness connectors
P/J22 and P/J221 between the MCU
Board and the Sub Drive Assembly.
Are the connectors securely
connected?
Go to step 6. Reconnect the
connectors. Go
to step 5.
5 Does the error still occur? Go to step 6. Complete.
6 Check the Sub Drive Assembly for
correct installation.
Is it correctly installed?
Go to step 8. Reseat the Main
Drive. Go to
step 7.
7 Does the error still occur? Go to step 8. Complete.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
