3-82 Phaser 6125/6130 Color Laser Printer Service Manual
Error Messages and Codes
Env Sensor Error
Humidity sensor error is detected.
Applicable Chain Link
■ 092-661: Env Sensor Error
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Procedure Table
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Humidity Sensor, PL8.2.7
■ MCU Board, PL8.2.13
■ “Map 3 - LVPS, Drive Motors, I/P Board,
AC Power” on page 10-10
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “Xerographic” on page 10-24
Step Actions and Questions Yes No
1 Reseat the connector (P/J201) on the
Humidity Sensor.
Does the error still occur when the
power is turned OFF and ON?
Go to step 2. Complete
2 Check the power to Humidity Sensor.
1.Disconnect the connector of J20
from the MCU Board.
2.Measure the voltage across P20-4
<=> ground on the MCU Board
Is the voltage about +5 VDC?
Replace the
Humidity Sensor
(page 8-58).
Replace the
MCU Board
(page 8-59).

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
