Phaser 6130 Color Laser Printer Service Manual 6-3
Adjustments and Calibrations
Enabling/Disabling Automatic Color Registration
This procedure provides instructions for how to enable or disable the
Automatic Color Registration function after a new Imaging Unit is installed.
■ If the function is set to On, the printer will calibrate the color alignment
every time it detects a new Imaging Unit.
■ If the function is set to Off, calibration will not occur. This allows users to
save toner.
To enable or disable the Automatic Color Registration:
1. From the Control Panel, press the Menu button.
2. Press the Up Arrow or Down Arrow button to find Admin Menu. Press
the OK button.
3. Press the Up Arrow or Down Arrow button to find Maintenance Mode.
Press the OK button.
4. Press the Up Arrow or Down Arrow button find Adjust Regi. Press the
OK button.
5. Press the Up Arrow or Down Arrow button to turn automatic color
registration On or Off.
Adjusting Color Registration
Color Registration can be automatically or manually adjusted.
Determining the Values
From the lines to the right of the Y (yellow), M (magenta), and C (cyan)
pattern, find the values of the straightest lines.
When “0” is the value nearest the straightest line, you do not need to adjust
the color registration. When the value is not “0,” refer to “Manual Color
Registration Adjustment” on page 6-4.
Auto Adjustment
1. From the Control Panel, press the Menu button.
2. Press the Up Arrow or Down Arrow button to find Admin Menu. Press
the OK button.
3. Press the Up Arrow or Down Arrow button to find Maintenance Mode.
Press the OK button.
4. Press the Up Arrow or Down Arrow button find Adjust Color Regi.
Press the OK button.
5. The Auto Adjust menu is displayed. Press the OK button.
6. Are you sure? message is displayed. Press the OK button to start the
Auto Adjustment procedure.
7. The printer starts the auto Color Registration process.
8. When the auto Color Registration is completed, the Ready menu is
displayed.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
