Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 9-5
Parts List
Parts List 1.1 Covers
ID No. Name/Description
Part Number
1 Cover Top 848E20100
2 Tray Ext 050E24201
3 Cover Rear 848E20072
4 Cover Cst 848E20121
5 Cover Window Tnr (Toner Access Door) 848K10661
6 Cover Side R 848E20091
7 Cover Assy Front (with 8-17) 675K61041
8 Latch Front —
9 Plate Latch —
10 Spring Latch Out —
11 Button Latch —
12 Cover Front
13 Guide Belt —
14 Damper Front L —
15 Damper Front S —
16 Cover Harness —
17 Harness Assy A-OP (J2200-P2900) 962K60030
18 Shaft Pivot —
19A
19B
Control Panel Assy PDL (6130)
Control Panel Assy GDI (6125)
848K09303
848K16161
20 Cover Side L 848E20081
21 — —
99 Kit Shaft Pivot (with 18 × 2pcs) 675K54050

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
