Phaser 6125/6130 Color Laser Printer Service Manual 10-21
Plug/Jack and Wiring Diagrams
Signal Line Name Description
K MODE SOL ON (L)
+24VDC
ON/OFF signal of the Color Mode Switching Solenoid
K MODE SENSED (L)
+3.3VDC
Color mode detect signal of the Feeder Drive by the
Sensor Photo (Color Mode Switching Sensor)
MAIN MOT ON Drive control signal of the Main Drive
MAIN MOT ALARM
MAIN MOT CLK
MAIN MOT LOW
MAIN MOT CW/CCW
SUB MOT ON Drive control signal of the Sub Drive
SUB MOT ALARM
SUB MOT CLK
SUB MOT LOW
SUB MOT BRAKE
