Yamaha QL5 Reference Manual

Data List
43
Input/Output Specifications
Analog input specifications
*1. The sensitivity is the input level required for output at +4dBu (1.23V) or at the defined
level when all the faders and level controllers are set to the maximum value.
*2. XLR-3-31 connectors are balanced jacks (1=GND, 2=HOT, 3=COLD).
*3. 0dBu=0.775 Vms for all specifications.
*4. All the AD converters use 24-bit linear/128-times oversampling.
*5. The INPUT connectors have +48V DC (phantom power) jacks, each of which can be
turned on/off individually from the console software.
*6. QL1: INPUT1-16
Analog output specifications
*1. XLR-3-32 connectors are balanced jacks (1=GND, 2=HOT, 3=COLD).
*2. The PHONES connectors for stereo headphones are balanced jacks (Tip=LEFT,
Ring=RIGHT, Sleeve= GND).
*3. 0 dBu=0.775 Vms for all specifications.
*4. All the DA converters use 24-bit linear/128-times oversampling.
*5. The console has an internal switch for toggling the maximum output level.
*6. This is a value measured with the PHONES LEVEL knob set to 10 dB below the
maximum position.
*7. QL1: OMNI OUT 1-8
Digital input/output specifications
*1. QL1: 32ch Input/32ch Output@48kHz
Digital output specifications
*1. Channel Status of DIGITAL OUT
*2. XLR-3-32 type connectors are balanced. (1= GND, 2= HOT, 3= COLD)
Input
Connectors
Gain
Input
Impedance
Source
Impedance
Input Level
Connector
Sensitivity
*1
Defined Level
Maximum
Non-Clip Level
INPUT 1-32
*6
+66dB
7.5 kΩ
50-600 Ω
Mics &
600 Ω Lines
–82dBu
(61.6μV)
–62dBu
(0.616mV)
–42dBu
(6.16mV)
XLR-3-31
type
(Balanced)
*2
–6dB
–10dBu
(245mV)
+10dBu
(2.45V)
+30dBu
(24.5V)
Output
Connectors
Output
Impedance
Load
Impedance
Maximum
Output
Level SW
*5
Output Level
Connector
Defined Level
Maximum
Non-Clip
Level
OMNI OUT
1-16
*7
75 Ω 600 Ω Lines
+24dB
(default)
+4dBu
(1.23V)
+24dBu
(12.3V)
XLR-3-32 type
(Balanced)
*1
+18dB
–2dBu
(616mV)
+18dBu
(6.16V)
PHONES 15 Ω
8 Ω Phones –
75mW
*6
150mW
Stereo Phone Jack
(TRS)
(Unbalanced)
*2
40 Ω Phones –
65mW
*6
150mW
Connectors Format
Data
Length
Level Audio Connector
Primary/
Secondary
Dante
24bit or
32bit
1000Base-T
64ch Input/64ch Output
@48kHz
*1
etherCON CAT5e
Connectors Format
Data
Length
Level Connector
DIGITAL OUT
*1
AES/EBU AES/EBU Professional Use 24 bit RS422
XLR-3-32 type (Balanced)
*2
Byte Bit Field Name Fixed/Variable Data Description
0
0 Block Format
fixed
1 professional use
1Mode 0 audio
2-4 Emphasis 0x4 off
5 Fs Lock 0 lock
6-7 Sampling Frequency variable
0x0 others
0x3 32 kHz
0x2 44.1 kHz
0x1 48 kHz
1
0-3 Channel Mode
fixed
0x1 2ch mode
4-7 Users Bit Management 0x0 -
2
0-2 Use of AUX
fixed
0x1 24 bits Audio Data
3-7 Source 0x00 -
3 0-7 Multi Channel fixed 0x00 -
4
0-1 Digital Audio Reference Signal
fixed
0x0
-
2- 0
3-6 Sampling Frequency variable 0x0 others
7 Sampling Frequency Scan Flag fixed 0 -

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
