Yamaha QL5 Reference Manual

Channel Job
Reference Manual
74
5 CLOSE button
Closes the window.
NOTE
If you use QL5 settings data on the QL1, buttons will be shown crossed-out if they are assigned
to a channel that does not exist on that model.
Copying, moving, or initializing a channel
You can copy or move mix parameters between channels, or restore the parameters of a
specific channel to their default settings.
Copying the parameters of a channel
You can copy the mix parameter settings of a channel to another channel. When you execute
the copy operation, the settings will overwrite the parameters of the copy-destination.
You can copy between the following combinations of channels.
• Between input channels
• Between the STEREO L/R channel and MONO channel
• Between MIX channels
• Between MATRIX channels
CH COPY MODE window
This window enables you to copy channel settings.
STEP
1. In the Function Access Area, press the CH JOB button.
2. Press the COPY button in the CH JOB menu.
3. Press a [SEL] key to select the copy-source channel.
4. Press the [SEL] key for the copy-destination channel (multiple selections are
allowed).
5. If you have selected a MIX/MATRIX channel as the copy-source, use the buttons in
the COPY TARGET field to select the parameters you want to copy.
6. Press the COPY button to execute the copy.
Function
Access Area
CH JOB
menu
1 4 2 3

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
