Yamaha QL5 Reference Manual

Data List
44
I/O SLOT (1-2) specifications
A Mini-YGDAI card can be inserted into slots 1-2.
Only slot 1 supports serial interfaces.
Control I/O specifications
*1. Input pin: TTL level, w/ internal pull-up (47kΩ)
Output pin: Open drain output (Vmax=12V, maximum sink current/pin=75mA)
Power supply pin: Output voltage Vp=5V, Max. output current Imax=300mA
*2. 4 pin=+12V, 3 pin=GND, Lamp nominal power: 5W, Brightness (voltage) can be
adjusted from the software.
Electrical characteristics
All faders are nominal when measured. Output impedance of signal generator: 150 ohms
 Frequency Response. Fs= 48 kHz @20 Hz–20 kHz, referenced to the nominal
output level @1 kHz
*1. QL1: INPUT 1-16
*2. QL1: OMNI OUT 1-8
 Total Harmonic Distortion. Fs= 48 kHz
*1. QL1: INPUT 1-16
*2. QL1: OMNI OUT 1-8
*3. Total Harmonic Distortion is measured with a 18 dB/octave filter @80 kHz
 Hum & Noise. Fs= 48 kHz, EIN= Equivalent Input Noise
*1. QL1: INPUT 1-16
*2. QL1: OMNI OUT 1-8
*3. Hum & Noise are measured with A-weight filter.
Connectors Format Level Connector
MIDI
IN MIDI – DIN Connector 5P
OUT MIDI – DIN Connector 5P
WORD CLOCK
IN – TTL/75 Ω terminated BNC Connector
OUT – TTL/75 Ω BNC Connector
GPI (5IN/5OUT) – –
D Sub Connector 15P
(Female)
*1
NETWORK IEEE802.3 10BASE-T/100Base-TX RJ-45
LAMP
(QL5: x2, QL1: x1)
–
0V-12V XLR-4-31 type
*2
USB HOST USB 2.0 – USB A Connector (Female)
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-32
*1
OMNI OUT 1-16
*2
600 Ω
GAIN: +66dB
–1.5 0.0 0.5
dB
PHONES 8 Ω –3.0 0.0 0.5
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-32
*1
OMNI OUT 1-16
*2
600 Ω
+4 dBu @20 Hz–20 kHz, GAIN:
+66dB
0.1
%
+4 dBu @20 Hz–20 kHz, GAIN: –6dB 0.05
Internal OSC
OMNI OUT 1-16
*2
600 Ω Full Scale Output @1 kHz 0.02
PHONES 8 Ω
Full Scale Output @1 kHz, PHONES
Level Control: Max.
0.2
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-32
*1
OMNI OUT 1-16
*2
600 Ω
Rs= 150 Ω, GAIN: +66dB
Master fader at nominal level and
one Ch fader at nominal level.
–128
EIN
dBu
–62
Rs= 150 Ω, GAIN: –6dB
Master fader at nominal level and
one Ch fader at nominal level.
–84 –80
All INPUTs
OMNI OUT 1-16
*2
600 Ω
Rs= 150 Ω, GAIN: –6dB
Master fader at nominal level and all
INPUT 1-32
*1
in faders at nominal
level.
QL5:
–64
QL1:
–67
—
OMNI OUT 1-16
*2
600 Ω Residual Output Noise, ST Master Off –88
—PHONES 8 Ω
Residual Output Noise, PHONES
Level Control Min.
–88

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
