Yamaha QL5 Reference Manual

Data List
45
 Dynamic Range. Fs= 48 kHz
*1. QL1: INPUT 1-16
*2. QL1: OMNI OUT 1-8
*3. Dynamic Range are measured with A-weight filter.
 Sampling Frequency
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-32
*1
OMNI OUT 1-16
*2
600 Ω AD + DA, GAIN: –6dB 108 dB
—
OMNI OUT 1-16
*2
600 Ω DA Converter 112 dB
Parameter Conditions Min. Typ. Max. Unit
External Clock
Frequency
Range
Fs= 44.1 kHz
Fs= 45.9375 kHz (44.1 kHz +4.1667%)
Fs= 44.1441 kHz (44.1 kHz +0.1%)
Fs= 44.0559 kHz (44.1 kHz –0.1%)
Fs= 42.336 kHz (44.1 kHz –4.0%)
–200 +200 ppm
Fs= 48 kHz
Fs= 50 kHz (48 kHz +4.1667%)
Fs= 48.048 kHz (48 kHz +0.1%)
Fs= 47.952 kHz (48 kHz –0.1%)
Fs= 46.080 kHz (48 kHz –4.0%)
Jitter of PLL
DIGITAL IN Fs= 44.1 kHz
DIGITAL IN Fs= 48 kHz
10 ns
Internal Clock
Frequency
Word Clock : Int 44.1 kHz 44.1
kHz
Word Clock : Int 48 kHz 48
Accuracy
Word Clock : Int 44.1 kHz
–50 +50 ppm
Word Clock : Int 48 kHz
Jitter
Word Clock : Int 44.1 kHz 4.429
ns
Word Clock : Int 48 kHz 4.069

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
