P o w e r & C o n n e c t i o n s
Setting Up
What you will connect the QY70 to, and what you will connect to the
QY70, will depend entirely on your individual requirements, and it would be
impossible to cover all possibilities here. A few examples are provided
below to help you get started.
The Connectors
q DC IN Jack
This jack is only used when you are powering the QY70
from an optional AC adaptor instead of batteries. The DC output
cable from an optional Yamaha PA-3B AC Power Adaptor is
plugged in here.
■ NOTE
• The batteries are automatically disconnected when a plug is inserted
into the DC IN jack.
w qr e
r
Rear Panel
Right Side Panel
