66
T h e S o n g V o i c e M o d e
The Effect Send Display
The QY70 features a high-performance internal digital signal process-
ing system which provides a range of effects including reverb, delay,
modulation, distortion, and more. Three independent effect blocks are
provided — Reverb, Chorus, and Variation. The individual effects are
selected and modified via the EFFECT mode, described in detail on page
212. The VOICE mode mixer display provides acces to independent effect
send controls for each of the three effect blocks via the MENU sub-display:
press the [MENU] button, and then the function key next to “Effect Send”
on the display.
VOICE mode mixer display

Yamaha QY70 Specifications

General

Type	Music Sequencer
Polyphony	32 notes
Sequencer Capacity	20, 000 notes
Effects	Reverb, Chorus, Variation
MIDI	In/Out/Thru
Songs	20 songs
Display	LCD
Power Supply	6 x AA batteries or AC adapter
Connections	MIDI In/Out/Thru, Headphone, DC In
Tracks	16
