5 Description of the driving position
27
5.3.6 Blade lever
• Use this lever to command the blade.
• Push the lever forward to lower the blade. (A)
• Pull the lever back to raise the blade. (B)
• If the lever is released, it return to neutral posi-
tion and the blade remains in its position. (N)
• Use the switch on the blade lever to switch to
second gear.
5.2.9 2nd gear switch, page 21
WARNING
The blade movement is not secured by the locking lever, even when the latter is in the loc-
ked position.
Do not operate the blade lever when you are not using it.
5.4 Power socket
• The intake, located on the left under
the seat, works when the ignition key is in the
ON position.Appliances
up to 12V-120W
(10A) may be connected.
1= Lid
2= Power socket
IMPORTANT
Always close the lid if the plug is not used to seal for dust.
Prolonged
use when the engine is switched off may damage the battery.
