8.1 Bonnet
• The filling ports for the hydraulic oil tanks, engine oil, and coolant are under the bonnet.
WARNING
Do not open the bonnet during machine operation. Verification and topping off of the va-
rious levels should be done when the engine is stopped and the temperatures are brought
back down.
Opening the cover
1. Insert the starter key into the lock.
2. Turn the key anti-clockwise.
3. Pull the lever to unlock the safety mechanism. The cover opens.
1 = Exterior handle
2 = Key
A = Pull
Closing the cover
1. Close the cover.
2. Press on it until you hear a click.
3. Turn the key clockwise to activate the lock.
