7 Options
47
• A switch in the cockpit allows to launch the lubrication of the machine swivel points.
•
To refill the centralized greasing system, connect the grease pump on the filling connector
nipple (B).
3 Recommended greases and fluids, page 137
CAUTION
Do not plug the hole at the top of the tank in order not to block the filling.
DANGER
In case of over filling, the tank can burst and cause physical injuries.
A= Tank
B= Filling connector
MAX= Filling limit
7.17 Centralized greasing system
• The centralised lubrication automates the greasing of the swivel pins on your machine.It co-
mes with a timer allowing adjusting the lubrication cycle and time.
