Yealink SIP-T41S Administrator's Guide

Security Features
120
Web UI
Settings > Auto Provision > Self-Define RSA Pri Key
Parameter
static.auto_provision.rsa_pri_key.delete <y0000000000xx>.cfg
Description
It deletes the self-define RSA private key file.
Permitted
Values
http://localhost/all
Default
Blank
Supported
Devices
T57W, T54W, T53W, T53, T48U, T46U, T43U, T42U, T48S, T46S, T42S, T41S, T27G and CP920
[1]
X is an activation code ID. X=1-50.
[2]
If you change this parameter, the phone will reboot to make the change take effect.
Incoming Network Signaling Validation
Yealink phones support the following three optional levels of security for validating incoming network signaling:
l
Source IP address validation: ensure the request is received from an IP address of a server belonging to the set
of target SIP servers.
l
Digest authentication: challenge requests with digest authentication using the local credentials for the asso-
ciated registered account.
l
Source IP address validation and digest authentication: apply both of the above methods.
Topic
Incoming Network Signaling Validation Configuration
Incoming Network Signaling Validation Configuration
The following table lists the parameters you can use to configure the incoming network signaling validation.
Parameter
sip.request_validation.source.list <y0000000000xx>.cfg
Description
It configures the name of the request method for which source IP address validation will be applied.
Example:
sip.request_validation.source.list = INVITE, NOTIFY
Permitted
Values
INVITE, ACK, BYE, REGISTER, CANCEL, OPTIONS, INFO, MESSAGE, SUBSCRIBE, NOTIFY,
REFER, PRACK, UPDATE
Default
Blank
Parameter
sip.request_validation.digest.list <y0000000000xx>.cfg
Description
It configures the name of the request method for which digest authentication will be applied.
Example:
sip.request_validation.digest.list = INVITE, SUBSCRIBE
Permitted
Values
INVITE, ACK, BYE, REGISTER, CANCEL, OPTIONS, INFO, MESSAGE, SUBSCRIBE, NOTIFY,
REFER, PRACK, UPDATE
Default
Blank
Parameter
sip.request_validation.digest.realm <y0000000000xx>.cfg
Description
It configures the string used for the authentication parameter Realm when performing the digest

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
