Yealink SIP-T41S Administrator's Guide

Advanced Features
442
Example
features.pickup.blf_visual_enable = 1
features.pickup.blf_audio_enable = 1
When the monitored line receives an incoming call, the phone screen shows an incoming call to the monitored line
(for example, “6001<-6002”, 6001 is the monitored extension which receives an incoming call from 6002) (from
1008 to 1001), the following occurs on the phone:
l The phone plays a specific alert tone.
l The BLF key LED flashes red. On the T57W/T48U/T48S/T48G IP phone, the icon / flashes.
l The caller ID appears on the phone screen.
The following shows a visual alert for monitor line on T46S/G phones:
You can pick up the call to the monitored line, place a call to the monitored line, place a new call or back to the idle
screen.
LED Mode for BLF/BLF List Key
BLF LED Mode provides five kinds of definition for the BLF/BLF List key LED status. As there is no hard line key on
T57W/T48U/T48S/T48G phones, BLF LED mode configuration is applicable to any phones and expansion module,
except T57W/T48U/T48S/T48G and T19(P) E2/CP920 phones.
Topics
Supported BLF LED Modes
BLF LED Mode Configuration
Supported BLF LED Modes
The following table lists the LED statuses of the BLF/BLF list key when BLF LED Mode is set to 0, 1, 2, 3 or 4 respect-
ively. The default value of BLF LED mode is 0.
Line key/Expansion Module Key LED (configured as a BLF key or a BLF List key and BLF LED Mode is set to 0)
LED Status Description
Solid green The monitored user is idle.
Fast-flashing red
(200ms)
The monitored user receives an incoming call.
Solid red
The monitored user is dialing.
The monitored user is talking.
The monitored user’s conversation is placed on hold (This LED status requires server sup-
port).
Slowly-flashing red (1s) The call is parked against the monitored user’s phone number.

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
