Yealink SIP-T41S Administrator's Guide

General Features
498
Reboot in Talking Configuration
The following table lists the parameter you can use to configure the reboot in talking.
Parameter
features.reboot_in_talk_enable <y0000000000xx>.cfg
Description
It enables or disables the phone to reboot during a call when it receives a reboot Notify message.
Permitted
Values
0-Disabled
1-Enabled
Default
0
Web UI
Features > General Information > Reboot in Talking
Reserve # in User Name
Reserve # in User Name feature allows the phones to reserve “#” in user name. When Reserve # in User Name fea-
ture is disabled, “#” will be converted into “%23”. For example, the user registers an account (user name: 1010#) on
the phone, the phone will send 1010%23 instead of 1010# in the REGISTER message or INVITE message to the
SIP server.
Example of a SIP REGISTER message:
INVITE sip:2@10.2.1.48:5060 SIP/2.0
Via: SIP/2.0/UDP 10.3.20.6:5060;branch=z9hG4bK1867789050
From: "1010" <sip:1010%23@10.2.1.48:5060>;tag=1945988802
To: <sip:2@10.2.1.48:5060>
Call-ID: 0_2336101648@10.3.20.6
CSeq: 1 INVITE
Contact: <sip:1010%23@10.3.20.6:5060>
Content-Type: application/sdp
Allow: INVITE, INFO, PRACK, ACK, BYE, CANCEL, OPTIONS, NOTIFY, REGISTER, SUBSCRIBE, REFER,
PUBLISH, UPDATE, MESSAGE
Max-Forwards: 70
User-Agent: Yealink SIP-T46G 28.82.0.20
Allow-Events: talk,hold,conference,refer,check-sync
Content-Length: 300
Topic
Reserve # in User Name Configuration
Reserve # in User Name Configuration
The following table lists the parameter you can use to configure the reserve # in user name.
Parameter
sip.use_23_as_pound <y0000000000xx>.cfg
Description
It enables or disables the phone to reserve the pound sign (#) in the user name.
Permitted
Values
0-Disabled (convert the pound sign into “%23”)
1-Enabled

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
