Yealink SIP-T58A User Manual

User Guide for SIP-T58V/A Smart Media Phone
346
To resume the held multicast RTP session, tap the Resume soft key.
The multicast RTP session is established again.
 Tap the EndCall soft key to cancel the multicast RTP session.
 Tap the Record soft key to record a call.
To stop recording, tap the Stop soft key.
Music on Hold
Music on hold (MoH) is the business practice of playing recorded music to fill the silence that
would be heard by the party placed on hold. To use this feature, you should specify a SIP URI
pointing to a Music on Hold Server account. When a call is placed on hold, the phone will send a
SIP INVITE message to the Music on Hold Server account. The Music on Hold Server account
automatically answers the SIP INVITE messages and immediately plays audio from some source
located anywhere (LAN, Internet) to the held party. Contact your system administrator for the
SIP URI.
To configure music on hold server via web user interface:
1. Click on Account->Advanced.
2. Select the desired account from the pull-down list of Account.
3. Enter the SIP URI (e.g., sip:moh@sip.com) in the Music Server URI field.
4. Click Confirm to accept the change.
When you place a call on hold, music will be played to the held party.
Note
For this feature to function, all involved parties cannot use encrypted RTP (SRTP).
Music on hold server is configurable via web user interface only.

Yealink SIP-T58A Specifications

General

Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Operating system version	5.1.1
Operating system installed	Android
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Bluetooth	No
Security algorithms	SRTP
Networking standards	IEEE 802.1x
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS, IPv4/IPv6, UDP/TCP/DNS-SRV
USB 2.0 ports quantity	2
Voice codecs	G.711Mu, G.711a, G.722, G.722.1, G.722.1C, G.723, G.726, G.729ab, iLBC
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Front camera resolution (numeric)	2 MP
Base station keys	27
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
Power consumption (typical)	1.9 W
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	220 mm
Width	259.4 mm
Height	239 mm
Package depth	293 mm
Package width	324 mm
Package height	128 mm
