Cables
This section describes how to set up and use the cables. The cables are available with a variety of connection
capabilities.
The following communication/charge cables are available:
•
USB Charging cable
• Provide the MC67 with operating and charging power when used with the Zebra approved power
supply.
• Synchronize information between the MC67 and a host computer. With customized or third pa
rty
sof
tware, it can also synchronize the MC67 with corporate databases.
•
Charge Only cable
• Provide the MC67 with operating and charging power when used with the Zebra approved power
supply.
•
Auto Charge cable.
• Provide the MC67 with operating and charging power when used with the Zebra approved power
supply.
•
DEX cable
• Provides communication with electronic data exchange devices, such as vending machines.
Battery Charging and Operating Power
The communication/charge cables can charge the MC67 battery and supply operating power.
To charge the MC67 battery:
1. Connect the communication/charge cable power input connector to the Zebra approved power source.
2. Slide the bottom of the MC67 into the connector cup end of the communication/charge cable and gently
press in until it
latches into the MC67.
3. Slide the two locking tabs up until they both lock into position.
Table 10-5
Battery LED Charging Indicators
LED Indication
Off No battery in slot; battery is not charging; battery is not inserted correctly in the charger;
charger is not powered.
Slow Blinking Amber Battery is charging.
Solid Amber Charging complete.
Fast Blinking Amber Charging error.
