Air filter maintenance
Recovery of the mainair cleaner element
Replacing the safety element of the air cleaner
The air filter is located in the front part of the tractor and is
accessible after the front bonnet has been lifted off.
Air filter maintenance shall be carried out once air filter
pollution gets signalled.
Carry out the air filter maintenance according to the
following procedure:
1. Lift off the front bonnet
2. Loosen the clips of the air filter cover (marked with
arrows)
3. Take off the filter cover (1)
NM14D014
Remove the main element of the dry cleaner (2) by
pulling. If the main element is not damaged (there must
not be any dust on the inner side of the element), recover
it by blowing pressurized air from the inner side of the
element. This way you can recover the main element
3 times at the most. The element must be replaced once
a year.
NM14D015
- remove dry filter locking element (3) with a pull
Locking element cannot be regenerated. It must
be always replaced in these cases:
- when damaging main element
- after 5 maintenances of air filter
- at least once in two years
NM14D016
