Activation of the rear PTO shaft - independent revolutions - common working mode
MCL18N027
The number of PTO shaft revolutions depends on the number of engine revolutions.
When the tractor is not going with its engine running:
A - Use the lever (1) to select appropriate revolutions of the rear PTO shaft - 540 or 1,000 rpm
B - Sit on the driver's seat.
C - Pull the manual clutch lever to the upper position.
D - Move the lever for activation of the PTO shaft drive from the position (n) to the position (b).
After the manual clutch lever is released to the lower position, the rear PTO shaft starts to rotate.
During operation of the rear PTO shaft in the independent rotation mode - common working
mode - the operator must sit on the driver's seat.
Pull the clutch release lever for the manual deactivation of the rear PTO shaft for short-term interruption of
torque transmission from the engine.
Move the lever for activation of the PTO shaft drive to the position (n) for long-term interruption of torque
transmission from the engine.
The number of revolutions of the independent PTO shaft see the chapter Main technical parameters.
MCL18N028
If the operator during the work with the rear PTO shaft leaves the driver's seat and the manual
clutch lever is not in the upper position or the lever for activation of the rear PTO shaft drive is not in
the neutral (n) position, an audio signal is generated, the PTO shaft symbol appears on the display of
the instrument panel and the engine is automatically shut off
.
DRIVE OF AGRICULTURAL MACHINERY
