Placement of fuses in fuse box
NM14D054
Pos. Fuse
size
Secured system
1 20A front and rear wiper
2 15A heating, air conditioning
3 20A work headlights
4 15A radio, washer, firer, beacon,
cabin lighting
5 10A dim light left
6 10A dim light right
7 15A position lights right
8 15A position lights left, number plate
lighting
9 15A distance lights with signal lamp
10 20A supply of the instrument panel
11 15A brake lights
12 15A direction lights
13 80A glowing
14 unoccupied
15 3A front PTO
16 30A engine control unit
17 25A fuel pump
