Zetor MAJOR CL User Manual

Hydraulic syste
m
Tractor´s speed in km/h with engine nominal revolutions
Performance on rear PTO shaft
Type of tractor Major 60 Major 80
Maximal lifting force at the end of lower draw bars of
rear three-point linkage when maximum useful pressure
(kN)
26
Lifting force at the end of lower draw bars of rear three-
point linkage in the whole range of heave with
maximum useful pressure (kN)
24
Hydraulic system pump supply (l/min) 50
Working pressure (MPA) 18
Gear
reduction
Gear Forward speed Reversing speed
L
1 L 1.43 1.20
2 L 2.12 1.78
3 L 3.11 2.61
4 L 4.37 3.67
M
1 M 3.64 3.05
2 M 5.39 4.52
3 M 7.89 6.62
4 M 11.08 9.30
H
1 H 9.65 8.11
2 H 14.29 12.00
3 H 20.91 17.56
4 H 29.39 24.68
Performance on PTO shaft (kW ± 2%)
- with nominal engine revolutions and engaged 1000
rpm of PTO shaft
Major 60 Major 80
Nominal engine revolutions (2200 rpm) 38,4 48,6
MAIN TECHNICAL PARAMETERS
124

Zetor MAJOR CL Specifications

General

Brand	Zetor
Model	MAJOR CL
Category	Tractor
Language	English
