Wiring with the logic relay
134
1SVC 440 795 M0100
• The power supply of the logic relay is no longer present.
•The OK or DEL + ALT buttons are used to switch to a
menu.
• A setpoint is entered.
• The text for D1 is displayed.
D1:
D1 is designed as an alarm text. If D1 is activated, the text
assigned to it will be displayed until
• The coil D1 is reset to 0.
• STOP mode is selected.
• The power supply of the logic relay is no longer present.
•The OK or DEL + ALT buttons are used to switch to a
menu.
Text entry
Text entry is only possible using CL–SOFT.
Character set
All ASCII characters in upper and lower case are permissible.
• A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
• a b c d e f g h i j k l m n o p q r s t u v w x y z
The following special characters are permissible:
! „“ # $ % & ’ () * + , – ./0 1 2 3 4 5 6 7 8 9
Figure 57: Text output examples
Counter with actual value Analog input scaled as
temperature value
D1 as error message on
fuse failure
QUANTITY
PCE:0042
!COUNTING!
TEMPERATURE
OUT -010 DEG
IN +018 DEG
HEAT
FUSE FAULT
HOUSE 1
FAILED!
