Page #60 background image
57
1SVC 440 795 M0100
3 Commissioning
Switching on Before switching on, check that you have connected the
power supply terminals and inputs correctly:
24 V AC version CL-AC1
Terminal L: Phase conductor L
Terminal N: Neutral conductor N
Terminals I1 to I12:
Actuation via same phase conductor L
230 V AC version CL-AC2
Terminal L: Phase conductor L
Terminal N: Neutral conductor N
Terminals I1 to I12, R1 to R12:
Actuation via phase conductor L
•12V DC version:
Terminal +12 V: voltage +12 V
Terminal 0 V: voltage 0 V
Terminals I1 to I12:
Actuation via same +12V
•24V DC version:
Terminal +24 V: voltage +24 V
Terminal 0 V: voltage 0 V
Terminals I1 to I12, R1 to R12:
Actuation via the same +24 V
If you have already integrated the logic relay into a system,
secure any parts of the system connected to the working
area to prevent access and ensure that no-one can be injured
if, for example, motors start up unexpectedly.
