Deleting the circuit diagram
X Switch the logic relay to the STOP mode.
The display shows
STOP å RUN.
X Use PROGRAM... to switch from the main menu to the
next menu level.
X Select DELETE PROGRAM
The logic relay shows the query
DELETE?.
X Press OK to delete the program or ESC to cancel.
Press ESC to return to the status display.
Fast circuit diagram entry
You can create a circuit diagram in several ways: The first
option is to enter the elements in the circuit and then to wire
all the elements together. The other option is to use the
enhanced operator guidance of the CL and create the circuit
diagram in one go, from the first contact through to the last
coil.
If you use the first option, you will have to select some of the
elements in order to create and connect up your circuit
diagram.
The second, faster option is what you learned in the
example. In this case you create the entire rung from left to
right.
h
The logic relay must be in STOP mode in order to extend,
delete or modify the circuit diagram.
PROGRAM
DELETE PROG
