Setting the menu language
63
1SVC 440 795 M0100
From the first contact to the output coil
With the logic relay you work from the input to the output.
The first input contact is
I1.
X Press OK.
The logic relay proposes the first contact
I1 at the cursor
position.
X I flashes and can be changed, for example, to a P for a
pushbutton input using the cursor buttons Í or Ú.
However, nothing needs to be changed at this point.
X Press OK 2 x, to move the cursor across the 1 to the
second contact field.
You could also move the cursor to the next contact field
using the cursor button
í.
X Press OK.
Again, the CL inserts a contact
I1 at the cursor position.
Change the contact number to
I2 so that n/c contact S2 can
be connected to input terminal I2.
X Press OK so that the cursor jumps to the next position and
use cursor buttons Í or Ú to change the number
2.
X Press OK to move the cursor to the third contact field.
You do not need a third relay contact, so you can now wire
the contacts directly up to the coil field.
I1 êê êê êêê
I1 I1 êê êêê
h
Press DEL to delete a contact at the cursor position.
I1-I2 Â
