Appendix
270
1SVC 440 795 M0100
List of the function relays Usable contacts
Contact type n/o n/c CL-LSR/
CL-LST
CL-LMR/
CL-LMT
Page
Analog value comparator
function relay
A a A1…A16 A1…A16 98
Counter function relays C c C1…C16 C1…C16 111
Text display function relay D D1…D16 D1…D16 131
Week time switch function relay Ö ö Ö1…Ö8 Ö1…Ö8 137
CL input terminal I i I1…I8 I1…I12 77
0 signal I13 I13
Expansion status – I14 236
Short-circuit/overload I16 I15…I16 234
Markers, (auxiliary relay) M m M1…M16 M1…M16 85
Markers (auxiliary relay) N N1…N16 N1…N16
Operating hours counter O O1…O4 O1…O4 143
Cursor button P p P1…P4 P1…P4 82
CL output Q q Q1…Q4 Q1…Q8 77
Input terminal for expansion unit R – R1…R12 77
Short-circuit/overload with
expansion
R – R15…R16 234
CL output (expansion or
auxiliary marker S)
S S1…S8
(as marker)
S1…S8 85
Timer function relays
T t T1…T16 T1…T16 148
Jump label : – :1…:8 :1…:8 164
Year time switch Y Y1…Y8 Y1…Y8 167
Master reset, (central reset)
Z Z1…Z3 Z1…Z3 174
