Changing parameters
203
1SVC 440 795 M0100
X Select the required function block with Í or Ú .
X Press the OK button.
X Use the cursor buttons Í or Ú to scroll through the
parameters.
X Change the values for a parameter set:
– Press OK to enter the Entry mode,
– Press
úí to change decimal place
– Press
ÍÚ to change the value of a decimal place,
– Press OK to save constants or
– ESC Retain previous setting.
Press ESC to leave the parameter display.
Adjustable parameters for function relays
You can also modify the function relay parameters used in
the circuit diagram in the PARAMETER menu.
Adjustable setpoint values are:
• With all function relays the setpoints
• On and off times with time switches.
In RUN mode the logic relay operates with a new setpoint as
soon as it has been modified in the parameter display and
saved with OK.
Example: Changing switch times for outdoor lighting
The outdoor lighting of a building is automatically switched
on from 19:00 to 23:30 Mondays to Fridays in the CL circuit
diagram.
h
You can enable or disable parameter access using the “+”
or “–” parameter set characters in the circuit diagram.
T3 Ü S +
I1 02.030
I2 05.000
T:
