ABB CL-LMR 18AC2 Series User Manual

Wiring with the logic relay
168
1SVC 440 795 M0100
Parameter display and parameter set for year time
switch
The parameter display for a year time switch is used to
modify the on time, the off time and to enable the parameter
display.
Table 13: On and off times
Parameter display in RUN mode:
Y1 A +
ON --.--.--
OFF --.--.--
Y3 Year time switch function relay 1
A,B,
C,D
Time switch channels
+ • + appears in the PARAMETER menu.
• - does not appear in the PARAMETER menu
ON On date: day, month, year (two-digit 2004 = 04)
OFF Off date: day, month, year (two-digit 2004 = 04)
Parameters
Meaning Meaningful values
xx.--.00 Date, day 01 to 31
--.xx.00 Month 01 to 12
--.-0.00 Year, two-digit 00 to 99
Selected channel
On time
Off time
# Contact has not switched.
â Contact has switched.
Y1 A +
ON 01.01.04
OFF 31.12.04
â
