Logic relay
14
1SVC 440 795 M0100
Device overview CL basic units at a glance
Figure 2: Device overview
a Supply voltage
b Inputs
c Operating status LED
d Keypad
e Interface for memory module or PC connection
f Outputs
g Display
DEL
ALT
ESC
OK
햳
햲
햸
햷
ESC
OK
DEL
ALT
햵
햴
햶
