Technical data
255
1SVC 440 795 M0100
Oscillations (IEC 60068-2-6)
10 to 57 Hz (constant amplitude 0.15 mm)
57 to 150 Hz (constant acceleration 2 g)
Shock (IEC 60068-2-27) 18 shocks (semi-sinusoidal 15 g/11 ms)
Drop (IEC 60068-2-31) Drop height 50 mm
Free fall, when packed (IEC 60068-2-32) 1 m
Electromagnetic compatibility (EMC)
Electrostatic discharge (ESD), (IEC/EN 61 000-4-2,
severity level 3)
8 kV air discharge,
6 kV contact discharge
Electromagnetic fields (RFI), (IEC/EN 61000-4-3) Field strength 10 V/m
Emitted interference Interference immunity
(EN 55011, EN 55022) IEC 61000-6-1,2,3,4
Class B
Fast transient burst (IEC/EN 61000-4-4,
severity level 3)
2 kV power cables,
2 kV signal cables
High-energy pulses (surge) CL-AC
(IEC/EN 61000-4-5)
2 kV power cable symmetrical
High-energy pulses (surge) CL-DC1, CL-DC2,
CL-AC1 (IEC/EN 61000-4-5, severity level 2)
0.5 kV power cable symmetrical
Immunity to line-conducted interference to
(IEC/EN 61000-4-6)
10 V
Insulation resistance
Clearance and creepage distances EN 50178, UL 508, CSA C22.2, No 142
Insulation resistance EN 50178
Overvoltage category/degree of pollution II/2
Tools and cable cross-sections
solid core min. 0.2 mm2, max. 4 mm2/AWG:22 – 12
Flexible with ferrule min. 0.2 mm
2
, max. 2.5 mm
2
/
AWG: 22 – 12
Factory wiring: to AWG 30
Slot-head screwdriver, width 3.5 x 0.8 mm
Tightening torque 0.6 Nm
