Name Values (Range) Unit Step Default Description
OperationSynch Disabled
Enabled
- - Disabled Operation for synchronizing function Off/On
FreqDiffMin 0.003 - 0.250 Hz 0.001 0.010 Minimum frequency difference limit for
synchronizing
FreqDiffMax 0.050 - 0.500 Hz 0.001 0.200 Maximum frequency difference limit for
synchronizing
FreqRateChange 0.000 - 0.500 Hz/s 0.001 0.300 Maximum allowed frequency rate of change
tBreaker 0.000 - 60.000 s 0.001 0.080 Closing time of the breaker
tClosePulse 0.050 - 60.000 s 0.001 0.200 Breaker closing pulse duration
tMaxSynch 0.00 - 6000.00 s 0.01 600.00 Resets synch if no close has been made before
set time
tMinSynch 0.000 - 60.000 s 0.001 2.000 Minimum time to accept synchronizing
conditions
OperationSC Disabled
Enabled
- - Enabled Operation for synchronism-check function
Off/On
VDiffSC 0.02 - 0.50 pu 0.01 0.15 Voltage difference limit for synchrocheck in p.u
of set voltage base value
FreqDiffA 0.003 - 1.000 Hz 0.001 0.010 Frequency difference limit between bus and
line Auto
FreqDiffM 0.003 - 1.000 Hz 0.001 0.010 Frequency difference limit between bus and
line Manual
PhaseDiffA 5.0 - 90.0 Deg 1.0 25.0 Phase angle difference limit between bus and
line Auto
PhaseDiffM 5.0 - 90.0 Deg 1.0 25.0 Phase angle difference limit between bus and
line Manual
tSCA 0.000 - 60.000 s 0.001 0.100 Time delay output for synchrocheck Auto
tSCM 0.000 - 60.000 s 0.001 0.100 Time delay output for synchrocheck Manual
AutoEnerg Disabled
DLLB
DBLL
Both
-
- DLLB Automatic energizing check mode
ManEnerg Disabled
DLLB
DBLL
Both
-
- Both Manual energizing check mode
ManEnergDBDL Disabled
Enabled
- - Disabled Manual dead bus, dead line energizing
tAutoEnerg 0.000 - 60.000 s 0.001 0.100 Time delay for automatic energizing check
tManEnerg 0.000 - 60.000 s 0.001 0.100 Time delay for manual energizing check
1MRK 511 287-UUS A Section 10
Control
225
Technical manual
