ABB REC650 ANSI User Manual

10.12.2 Function block
IEC10000284-1-en.vsd
I103USRCMD
BLOCK ^OUTPUT1
^OUTPUT2
^OUTPUT3
^OUTPUT4
^OUTPUT5
^OUTPUT6
^OUTPUT7
^OUTPUT8
IEC10000284 V1 EN
Figure 160: I103USRCMD function block
10.12.3 Signals
Table 248: I103USRCMD Input signals
Name Type Default Description
BLOCK BOOLEAN 0 Block of commands
Table 249: I103USRCMD Output signals
Name
Type Description
OUTPUT1 BOOLEAN Command output 1
OUTPUT2 BOOLEAN Command output 2
OUTPUT3 BOOLEAN Command output 3
OUTPUT4 BOOLEAN Command output 4
OUTPUT5 BOOLEAN Command output 5
OUTPUT6 BOOLEAN Command output 6
OUTPUT7 BOOLEAN Command output 7
OUTPUT8 BOOLEAN Command output 8
10.12.4 Settings
Table 250: I103USRCMD Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 1 Function type (1-255)
PulseMode Steady
Pulsed
- - Pulsed Pulse mode
PulseLength 0.200 - 60.000 s 0.001 0.400 Pulse length
InfNo_1 1 - 255 - 1 1 Information number for output 1 (1-255)
Table continues on next page
1MRK 511 287-UUS A Section 10
Control
361
Technical manual
