The binary input BLOCK can be used to block the function. The activation of the BLOCK
input deactivates all outputs and resets internal timers. The alarm signals from the function
can be blocked by activating the binary input BLK_ALM.
12.18.8 Technical data
Table 431: SSCBR Technical data
Function Range or value Accuracy
Alarm levels for open and close
travel time
(0-200) ms ± 0.5% ± 25 ms
Alarm levels for number of
operations
(0 - 9999) -
Setting of alarm for spring
charging time
(0.00-60.00) s ± 0.5% ± 25 ms
Time delay for gas pressure alarm (0.00-60.00) s ± 0.5% ± 25 ms
Time delay for gas pressure
lockout
(0.00-60.00) s ± 0.5% ± 25 ms
12.19 Measurands for IEC 60870-5-103 I103MEAS
12.19.1 Functionality
103MEAS is a function block that reports all valid measuring types depending on
connected signals.
The measurand reporting interval set for MMXU function blocks, using the xDbRepInt
and xAngDbRepInt settings, must be coordinated with the event reporting interval set for
the IEC 60870-5-103 communication using setting CycMeasRepTime.
Section 12 1MRK 511 287-UUS A
Monitoring
538
Technical manual
