11.9.2 Functionality
Elapsed Time Integrator (TEIGGIO) function is a function that accumulates the elapsed
time when a given binary signal has been high.
The main features of TEIGGIO are
• Applicable to long time integration (≤999 999.9 seconds).
• Supervision of limit transgression conditions and overflow.
• Possibility defining a warning or alarm with the resolution of 10 milliseconds.
• Retain the integration value at a warning/alarm/overflow.
• Possibilities for blocking and reset.
• Report the integrated time
11.9.3 Function block
TEIGGIO
BLOCK
IN
RESET
WARNING
ALARM
OVERFLOW
ACCTIME
IEC13000005-1-en.vsd
IEC13000005 V1 EN
Figure 195: TEIGGIO function block
11.9.4 Signals
Table 333: TEIGGIO Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Freeze the integration and block the other outputs
IN BOOLEAN 0 The input signal that is used to measure the elapsed
time, when its value is high
RESET BOOLEAN 0 Reset the integration time
Section 11 1MRK 511 287-UUS A
Logic
414
Technical manual
