Name Type Default Description
S289G_CL BOOLEAN 0 S289G on bus section 2 is in closed position
BBTR_OP BOOLEAN 0 No busbar transfer is in progress
VP_BBTR BOOLEAN 0 Status are valid for apparatuses involved in the busbar
transfer
EXDU_12 BOOLEAN 0 No transmission error from any bay connected to busbar
1 and 2
EXDU_89G BOOLEAN 0 No transmission error from bays containing grounding
switches QC1 or QC2
152O_EX1 BOOLEAN 0 External open condition for apparatus 152
152O_EX2 BOOLEAN 0 External open condition for apparatus 152
152O_EX3 BOOLEAN 0 External open condition for apparatus 152
189_EX1 BOOLEAN 0 External condition for apparatus 189
189_EX2 BOOLEAN 0 External condition for apparatus 189
289_EX1 BOOLEAN 0 External condition for apparatus 289
289_EX2 BOOLEAN 0 External condition for apparatus 289
Table 204: A1A2_BS (3) Output signals
Name
Type Description
152OPREL BOOLEAN Opening of 152 is allowed
152OPITL BOOLEAN Opening of 152 is not allowed
152CLREL BOOLEAN Closing of 152 is allowed
152CLITL BOOLEAN Closing of 152 is not allowed
189REL BOOLEAN Switching of 189 is allowed
189ITL BOOLEAN Switching of 189 is not allowed
289REL BOOLEAN Switching of 289 is allowed
289ITL BOOLEAN Switching of 289 is not allowed
389GREL BOOLEAN Switching of 389G is allowed
389GITL BOOLEAN Switching of 389G is not allowed
489GREL BOOLEAN Switching of 489G is allowed
489GITL BOOLEAN Switching of 489G is not allowed
S1S2OPTR BOOLEAN No bus section connection between bus section 1 and 2
S1S2CLTR BOOLEAN Bus coupler connection between bus section 1 and 2
exists
189OPTR BOOLEAN 189 is in open position
189CLTR BOOLEAN 189 is in closed position
289OPTR BOOLEAN 289 is in open position
289CLTR BOOLEAN 289 is in closed position
Table continues on next page
Section 10 1MRK 511 287-UUS A
Control
286
Technical manual
