Name Type Default Description
989_EX5 BOOLEAN 0 External condition for apparatus 989
989_EX6 BOOLEAN 0 External condition for apparatus 989
989_EX7 BOOLEAN 0 External condition for apparatus 989
Table 212: BH_CONN (3) Output signals
Name Type Description
152CLREL BOOLEAN Closing of 152 is allowed
152CLITL BOOLEAN Closing of 152 is not allowed
6189REL BOOLEAN Switching of 6189 is allowed
6189ITL BOOLEAN Switching of 6189 is not allowed
6289REL BOOLEAN Switching of 6289 is allowed
6289ITL BOOLEAN Switching of 6289 is not allowed
189GREL BOOLEAN Switching of 189G is allowed
189GITL BOOLEAN Switching of 189G is not allowed
289GREL BOOLEAN Switching of 289G is allowed
289GITL BOOLEAN Switching of 289G is not allowed
Table 213: BH_LINE_A (3) Output signals
Name
Type Description
152CLREL BOOLEAN Closing of 152 is allowed
152CLITL BOOLEAN Closing of 152 is not allowed
689REL BOOLEAN Switching of 689 is allowed
689ITL BOOLEAN Switching of 689 is not allowed
189REL BOOLEAN Switching of 189 is allowed
189ITL BOOLEAN Switching of 189 is not allowed
189GREL BOOLEAN Switching of 189G is allowed
189GITL BOOLEAN Switching of 189G is not allowed
289GREL BOOLEAN Switching of 289G is allowed
289GITL BOOLEAN Switching of 289G is not allowed
389GREL BOOLEAN Switching of 389G is allowed
389GITL BOOLEAN Switching of 389G is not allowed
989REL BOOLEAN Switching of 989 is allowed
989ITL BOOLEAN Switching of 989 is not allowed
989GREL BOOLEAN Switching of 989G is allowed
989GITL BOOLEAN Switching of 989G is not allowed
Table continues on next page
1MRK 511 287-UUS A Section 10
Control
311
Technical manual
