Function block
INVALIDQT
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
INPUT7
INPUT8
INPUT9
INPUT10
INPUT11
INPUT12
INPUT13
INPUT14
INPUT15
INPUT16
VALID
OUTPUT1
OUTPUT2
OUTPUT3
OUTPUT4
OUTPUT5
OUTPUT6
OUTPUT7
OUTPUT8
OUTPUT9
OUTPUT10
OUTPUT11
OUTPUT12
OUTPUT13
OUTPUT14
OUTPUT15
OUTPUT16
IEC09000305-1-en.vsd
IEC09000305 V1 EN
Figure 187: INVALIDQT function block
Function which sets quality invalid of outputs according to a "valid" input.
Inputs are copied to outputs. If input VALID is 0, or if its quality invalid bit is set, all
outputs invalid quality bit will be set. The timestamp of an output will be set to the latest
timestamp of INPUT and VALID input.
Signals
Table 313: INVALIDQT Input signals
Name
Type Default Description
INPUT1 BOOLEAN 0 InvalidLogic
INPUT2 BOOLEAN 0 Indication input 2
INPUT3 BOOLEAN 0 Indication input 3
INPUT4 BOOLEAN 0 Indication input 4
INPUT5 BOOLEAN 0 Indication input 5
INPUT6 BOOLEAN 0 Indication input 6
INPUT7 BOOLEAN 0 Indication input 7
INPUT8 BOOLEAN 0 Indication input 8
INPUT9 BOOLEAN 0 Indication input 9
INPUT10 BOOLEAN 0 Indication input 10
INPUT11 BOOLEAN 0 Indication input 11
INPUT12 BOOLEAN 0 Indication input 12
INPUT13 BOOLEAN 0 Indication input 13
Table continues on next page
1MRK 511 287-UUS A Section 11
Logic
395
Technical manual
