Functionality
Single position input is copied to value part of SP_OUT output. TIME input is copied to
time part of SP_OUT output. State input bits are copied to the corresponding state part of
SP_OUT output. If the state or value on the SP_OUT output changes, the Event bit in the
state part is toggled.
Function block
INDCOMBSPQT
SP_IN*
TIME*
BLOCKED*
SUBST*
INVALID*
TEST*
SP_OUT
IEC09000306-1-en.vsd
IEC09000306 V1 EN
Figure 188: INDCOMBSPQT function block
Signals
Table 315: INDCOMBSPQT Input signals
Name
Type Default Description
SP_IN BOOLEAN 0 SP_OUT
TIME GROUP
SIGNAL
0 SP_OUT
BLOCKED BOOLEAN 0 SP_OUT
SUBST BOOLEAN 0 Substituted
INVALID BOOLEAN 0 SP_OUT
TEST BOOLEAN 0 SP_OUT
Table 316: INDCOMBSPQT Output signals
Name
Type Description
SP_OUT BOOLEAN SP_OUT
Settings
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
1MRK 511 287-UUS A Section 11
Logic
397
Technical manual
