Table 513: SMAI_20_1 Non group settings (advanced)
Name Values (Range) Unit Step Default Description
Negation Disabled
NegateN
Negate3Ph
Negate3Ph+N
-
- Disabled Negation
MinValFreqMeas 5 - 200 % 1 10 Limit for frequency calculation in % of VBase
Even if the AnalogInputType setting of a SMAI block is set to Current, the
MinValFreqMeas setting is still visible. This means that the minimum
level for current amplitude is based on VBase. For example, if VBase is
20000, the minimum amplitude for current is 20000 * 10% = 2000. This
has practical affect only if the current measuring SMAI is used as a
frequency reference for the adaptive DFT. This is not recommended, see
the Setting guidelines.
Table 514: SMAI_20_12 Non group settings (basic)
Name Values (Range) Unit Step Default Description
GlobalBaseSel 1 - 6 - 1 1 Selection of one of the Global Base Value
groups
DFTReference InternalDFTRef
DFTRefGrp1
DFTRefGrp2
DFTRefGrp3
DFTRefGrp4
DFTRefGrp5
DFTRefGrp6
DFTRefGrp7
DFTRefGrp8
DFTRefGrp9
DFTRefGrp10
DFTRefGrp11
DFTRefGrp12
External DFT ref
- - InternalDFTRef DFT reference
ConnectionType Ph-N
Ph-Ph
- - Ph-N Input connection type
AnalogInputType Voltage
Current
- - Voltage Analog input signal type
Table 515: SMAI_20_12 Non group settings (advanced)
Name
Values (Range) Unit Step Default Description
Negation Disabled
NegateN
Negate3Ph
Negate3Ph+N
-
- Disabled Negation
MinValFreqMeas 5 - 200 % 1 10 Limit for frequency calculation in % of VBase
Section 15 1MRK 511 287-UUS A
Basic IED functions
612
