Table 540: Output contacts X321, 3U full 19”
Terminal Description PCM600 info
Hardware module
instance
Hardware channel
X321-1 Power output 1, normally open BIO_3 BO1_PO
X321-2
X321-3 Power output 2, normally open BIO_3 BO2_PO
X321-4
X321-5 Power output 3, normally open BIO_3 BO3_PO
X321-6
Table 541: Output contacts X326, 3U full 19”
Terminal Description PCM600 info
Hardware module
instance
Hardware channel
X326-1 Power output 1, normally open BIO_4 BO1_PO
X326-2
X326-3 Power output 2, normally open BIO_4 BO2_PO
X326-4
X326-5 Power output 3, normally open BIO_4 BO3_PO
X326-6
Table 542: Output contacts X331, 3U full 19”
Terminal
Description PCM600 info
Hardware module
instance
Hardware channel
X331-1 Power output 1, normally open BIO_5 BO1_PO
X331-2
X331-3 Power output 2, normally open BIO_5 BO2_PO
X331-4
X331-5 Power output 3, normally open BIO_5 BO3_PO
X331-6
Section 16 1MRK 511 287-UUS A
IED physical connections
638
Technical manual
