8.4.3.2 Setting example for generator application
In case of out of step conditions this shall be checked if the pole slip centre is inside
the generator (zone 1) or if it is situated in the network (zone 2).
IEC07000017 V1 EN
Figure 140: Generator application of pole slip protection
If the apparent impedance crosses the impedance line ZB – ZA this is the detected
criterion of out of step conditions, see figure 141.
1MRK 502 071-UEN - Section 8
Impedance protection
Generator protection REG670 2.2 IEC and Injection equipment REX060, REX061, REX062 271
Application manual
