ABB REG670 Applications Manual

Name of OUTx Type Description Value when
activated
Value when
deactivated
OUT9 BOOLEAN Output 9 256 0
OUT10 BOOLEAN Output 10 512 0
OUT11 BOOLEAN Output 11 1024 0
OUT12 BOOLEAN Output 12 2048 0
OUT13 BOOLEAN Output 13 4096 0
OUT14 BOOLEAN Output 14 8192 0
OUT15 BOOLEAN Output 15 16384 0
OUT16 BOOLEAN Output 16 32768 0
The sum of the numbers in column “Value when activated” when all OUTx (1≤x≤16)
are active equals 65535. This is the highest integer that can be converted by the
ITBGAPC function block.
16.12 Pulse integrator TIGAPC
16.12.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Pulse integrator TIGAPC
16.12.2 Application
The pulse integrator function TIGAPC is intended for applications where there is a
need for a integration of a pulsed signal. For example, the pulses from the start output
of certain functions, like reverse power, loss of excitation and pole slip. Some
applications may require the integration of the start output of those functions to
perform the trip.
16.12.3 Setting guidelines
The pulse integrator function provides settings for time delay to operate and time
delay to reset. The time delay to operate setting is evaluated for activation of the output
and there will be no output until the integration of the input pulses equals this setting.
The output will be deactivated when the input signal is deactivated and the time delay
to reset has elapsed.
Section 16 1MRK 502 071-UEN -
Logic
616 Generator protection REG670 2.2 IEC and Injection equipment REX060, REX061, REX062
Application manual
